This series Indicator light (pilot light)are used as indicating, accidental signals & other pilot signal of instrumental circuit in the area of eletric power , telecommunication, machinery, marine, textile, priting ,mining etc.
| Colors | Red |
|---|---|
| Yellow | |
| Blue | |
| Green | |
| Amber | |
| Rated voltage | AC/DC – 110V,24V, 12V , 48V :-AC- 220V |
| Rated operational current | ≤ 20mA |
| Service life | ≥ 15000h |
| Brightness | ≥ 60cd/m² |
| Degree of protection | IP65 |
| Ambient temperature | ≥- 5°C … + 70°C |
| Altitude | ≤ 2000m |
| Relative Humidity | 50% at +40°C |
| 90% at +20°C |
